2017 176-Ton x 10′ Bystronic Xact Smart 160 CNC Press Brake | Stock #4588
Have one to sell?
ConditionUsed
1 available
Boost your fabrication capabilities with this 2017 Bystronic Xact Smart 160 CNC Press Brake, engineered to deliver exceptional bending accuracy, productivity, and reliability. Featuring 176 tons of forming capacity and a 10' (122") bending length, this machine is an excellent choice for shops producing precision sheet metal components in both prototype and production environments.
Equipped with the user-friendly ByVision Bending CNC Control, the Xact Smart provides intuitive programming, fast setup times, and repeatable precision, helping operators maximize efficiency while maintaining superior part quality.
Press Force: 176 Tons
Bending Length: 122″
Standard Stroke: 7.9″
Open Height: 18.9″
Distance Between Side Frames: 96.5″
Throat: 15.8″
Table Width: 2.4″
Travels
X-Axis: 23.6″
R-Axis: 5.9″
Z-Axis: 72″
Max Back Gauge Range X-Axis: 33.5″
Speed
X-Axis: 1417.3 ipm
R-Axis: 472.4 ipm
Z-Axis: 2362.2 ipm
Max Y-Approach Speed: 330.7 ipm
Max Y-Working Speed: 23.6 ipm
Position Accuracy
X-Axis: 0.002″
R-Axis: 0.002″
Y-Axis: 0.0004″
Main Motor Power: 14.8 HP
ByVision Bending CNC Control
